Multistage Pump
D Series Horizontal Multistage Pump
- OEM
- Factory Direct Supply
- ISO9001 Certified
Product Overview
Product Description
D Series Horizontal Multistage Pump – Built for Extreme High-Pressure Duty
Balanced multistage impeller design minimizes axial thrust and extends bearing life. Segmentally constructed casing enables easy stage addition or removal for flow/head adjustment. High-voltage motors (6kV/10kV) available for large-scale installations. Wear-resistant rings protect critical components. ISO certified.
KEY FEATURES
- Extreme High-Head Capability: Multistage design delivers up to 1850m head, meeting the most demanding high-pressure transfer requirements.
- Wide Flow Range: Handles flows from 3.75 to 1350 m³/h, covering small to large-scale applications.
- High Pressure Tolerance: Designed for maximum working pressure of 3.0 MPa (30 bar / 435 psi), ensuring reliable operation.
- High-Voltage Motor Options: Available with 6kV and 10kV high-voltage motors for large industrial installations.
- Clean Water Optimized: Specifically engineered for清水 (clean water) and liquids with similar physical-chemical properties, without solids or suspended particles.
Specifications
Technical Parameters
| Parameter | Specification | Parameter | Specification |
|---|---|---|---|
| Product Name | D Series Horizontal Multistage Pump | Model | D |
| Category | Horizontal Multistage Pump | Flow Rate | 3.75 - 1350 m³/h |
| Head | 16 - 1850 m | Power | 3 - 630 kW |
| Speed | 1450 / 2900 rpm | Voltage | 380 V / 415V / 6kV / 10kV V |
| Suction & Discharge Diameter | 40 - 350 mm | Max. Working Pressure | ≤ 3.0 MPa |
| Pump Body Material | Cast Iron / Cast Steel / Stainless Steel | Seal Type | Mechanical Seal / Packing Seal |
| Motor Protection Class | IP55 | Insulation Class | F or H |
| Installation Type | Horizontal | Certification | ISO9001 / ISO14001 / ISO45001 |
Manufacturing
Precision engineering, advanced facilities.
Certifications
Global certifications for reliable performance.
OEM/ODM
Tailor-made pumps for your specifications.
Packaging
Robust export packaging for safe delivery.
Use Cases
Applications
Reliable High-Pressure Water Supply for Mining, Industrial & Municipal Applications The D series horizontal multistage pump is specifically engineered for demanding high-pressure clean water applications, offering exceptional reliability and efficiency.
-
Mine Drainage
Ideal for underground mine dewatering and water removal, handling clear water without solids or suspended particles.
-
Factory Water Supply
Perfect for industrial plant pressure boosting, production line water supply, and circulating systems.
-
Municipal Water Supply
Suitable for city water distribution networks, high-rise building pressurization, and community water systems.
-
Power Generation
Reliable for power plant cooling water circulation and auxiliary water systems.
-
Irrigation Systems
Effective for large-scale agricultural irrigation and farmland drainage projects requiring high head.
Frequently Asked Questions
What is the maximum head this D series multistage pump can achieve?
What type of liquid quality is required for this pump?
What high-voltage motor options are available?
What materials are available for corrosive or high-temperature applications?
What is the typical maintenance requirement for this multistage pump?
Have more questions? Our technical team is ready to help you select the right pump model.
Need Help Selecting the Right Pump?
Our engineering team will provide a professional selection recommendation within 24 hours based on your specific requirements.
